Product Glance
Power on wall @35°C(1-2), Watt(1-1)
5590
Power efficiency on wall @35°C(1-2), J/TH(1-1)
13.0
Power Supply
Power supply AC Input voltage, Volt(2-1)
120~210V/340~400V
Power supply AC Input Frequency Range, Hz
50~60
Power supply AC Input current, Amp(2-2)
12
Hardware Configuration
Networking connection mode
RJ45 Ethernet 10/100M
Miner Size (Length*Width*Height, w/o package), mm(1-2)
339*173*207
Miner Size (Length*Width*Height, with package), mm
570*316*430
Environment Requirements
Water flow, L/min
8.0~10.0
Working fluid(2-4)
Antifreeze/Pure water/Deionized water
Diameter of water pipe connector, mm
DN10
Storage temperature, °C
-20~70
Operation humidity(non-condensing), RH
10~90%
NOTE:
(1-1) The Hashrate value, Power on wall, and Power efficiency on wall are all typical values, The actual Hashrate value fluctuates by 3%, and the actual Power on wall and Power efficiency on wall fluctuate by 5%.
(1-2) Inlet water temperature.
(2-1) Caution: Wrong input voltage may probably cause server damaged.
(2-2) Three-phase AC input, 10 A per wire.
(2-3) NEM: Normal Energy Mode; HEM: High Energy Mode.
(2-4) If the water conductivity is ≥100 μs/cm, the fluid must be replaced. The water conductivity is less than 20 μs/cm when the system is running at the first time.
Please click here to refer to the all certificates of the products.
